基于特征的图像变形算法，来源于1992年的一篇论文。它是分别在两幅图像中分别选择相应的特征对（特征线段对），然后根据原始像素与每个特征的相对位置，映射原始像素，再取加权平均得出最终的像素值。

如下图是特征线段对为2个的情况：

特征线段可以是交互产生的，也可以是自动检测的。

图像变形采用的是双线性插值的反向映射算法。

具体的算法推演，博客开头列出的资料1和2已经讲得很明白了，而且给出了算法实现的伪代码，以及基于OpenCV1的C代码。

这篇博客所做的工作是将上述C代码，完全翻译为C++代码。模块解耦清晰，没有一大堆烦人的全局变量，易于理解。

改写后的代码基于OpenCV2。运行程序的使用方法与原程序同，见参考资料2。

废话不多说了，贴代码。

代码实现

主函数文件 Main.cpp

#include<string.h>
#include"Morpher.h"

int main()
{
    Morpher morpher;
    morpher.main();

    return EXIT_SUCCESS;
}

头文件 Morpher.h，包含几个类的定义。

#include <stdio.h>
#include <stdlib.h>
#include <iostream>
#include <vector>
#include <string>
#include <math.h>

#include <opencv2/opencv.hpp>
#include <opencv2/highgui/highgui.hpp>


using namespace std;
using namespace cv;


class Line
{
public:
    //起点、终点、中点、线长、角度
    Point2f P=Point2f(0.f,0.f);
    Point2f Q = Point2f(0.f, 0.f);
    Point2f M = Point2f(0.f, 0.f);
    double len{0};
    float degree{0};

    //参数a,b,p
    double a=1.0;
    double b=2.0;
    double p=1.0;

public:
    Line() :P(Point2f(0.f, 0.f)), Q(Point2f(0.f, 0.f)){};

    //由P,Q坐标得到中点，线长，角度信息
    void PQtoMLD();

    void MLDtoPQ();
    void show();

    double Getu(Point2f X);
    double Getv(Point2f X);
    Point2f Get_Point(double u, double v);
    double Get_Weight(Point2f X);
};


class LinePair
{
public:
    Line leftLine;
    Line rightLine;
    vector<Line> warpLine;

public:

    //生成中间过渡的线段集合
    void genWarpLine(int frame_count);
};


class Image
{
public:

    //过渡帧序号
    int frame_index;

    Mat left_image;
    Mat right_image;
    Mat new_image;

public:
    Image(int frame_index,string leftImageName,string rightImageName);

    //双线性插值
    Vec3b bilinear(Mat image, double X, double Y);

    //生成过渡图像帧
    void Warp(int frame_count, string new_image_name, vector<LinePair> pairs);
};


class Morpher
{
public:
    vector<LinePair> pairs;
    LinePair curLinePair;

    //计数，交互式画线要用到
    int counter = 0;

    //设置动画的过渡帧，比如1为50%，3为25%，50%，75%
    int frame_count = 1;

    Mat leftImage;
    Mat rightImage;
    Mat leftImageTmp;
    Mat rightImageTmp;

    //显示相关。画线的颜色、线宽、偏移
    Scalar color = Scalar(0, 255, 0);
    int thickness = 2;
    int shift = 0;

    //按键值，用于控制
    int key;

    string first_image_name;
    string second_image_name;
    string new_image_name;


public:
    void show_pairs();

    //捕获左图像上的鼠标动作
    static void on_mousel(int event, int x, int y, int flag, void* param);

    //捕获右图像上的鼠标动作
    static void on_mouser(int event, int x, int y, int flag, void* param);

    //运行morph
    void runWarp();

    void main();

};

实现文件 Morpher.cpp，类函数的具体实现。

#include"Morpher.h"


void Line::PQtoMLD()
{
    M.x = (P.x + Q.x) / 2;
    M.y = (P.y + Q.y) / 2;

    float tmpx = Q.x - P.x;
    float tmpy = Q.y - P.y;

    len = sqrt(tmpx*tmpx + tmpy*tmpy);
    degree = atan2(tmpy, tmpx);
    return;
}

void Line::MLDtoPQ()
{
    float tmpx = 0.5*len*cos(degree);
    float tmpy = 0.5*len*sin(degree);

    Point2f tmpP;
    Point2f tmpQ;
    tmpP.x = M.x - tmpx;
    tmpP.y = M.y - tmpy;
    tmpQ.x = M.x + tmpx;
    tmpQ.y = M.y + tmpy;

    P = tmpP;
    Q = tmpQ;
    return;
}

void Line::show()
{
    printf("P(%lf,%lf) Q(%lf,%lf) M(%lf,%lf)\n \tlen=%lf degree=%f\n", P.x, P.y, Q.x, Q.y, M.x, M.y, len, degree);
    return;
}

double Line::Getu(Point2f X)
{
    double X_P_x = X.x - P.x;
    double X_P_y = X.y - P.y;
    double Q_P_x = Q.x - P.x;
    double Q_P_y = Q.y - P.y;
    double u = ((X_P_x * Q_P_x) + (X_P_y * Q_P_y)) / (len * len);
    return u;
}

double Line::Getv(Point2f X)
{
    double X_P_x = X.x - P.x;
    double X_P_y = X.y - P.y;
    double Q_P_x = Q.x - P.x;
    double Q_P_y = Q.y - P.y;
    double Perp_Q_P_x = Q_P_y;
    double Perp_Q_P_y = -Q_P_x;
    double v = ((X_P_x * Perp_Q_P_x) + (X_P_y * Perp_Q_P_y)) / len;
    return v;
}

Point2f Line::Get_Point(double u, double v)
{
    double Q_P_x = Q.x - P.x;
    double Q_P_y = Q.y - P.y;
    double Perp_Q_P_x = Q_P_y;
    double Perp_Q_P_y = -Q_P_x;
    double Point_x = P.x + u * (Q.x - P.x) + ((v * Perp_Q_P_x) / len);
    double Point_y = P.y + u * (Q.y - P.y) + ((v * Perp_Q_P_y) / len);
    Point2f X;
    X.x = Point_x;
    X.y = Point_y;
    return X;
}

double Line::Get_Weight(Point2f X)
{
    double d = 0.0;

    double u = Getu(X);
    if (u > 1.0)
        d = sqrt((X.x - Q.x) * (X.x - Q.x) + (X.y - Q.y) * (X.y - Q.y));
    else if (u < 0)
        d = sqrt((X.x - P.x) * (X.x - P.x) + (X.y - P.y) * (X.y - P.y));
    else
        d = abs(Getv(X));


    double weight = pow(pow(len, p) / (a + d), b);
    return weight;
}




void LinePair::genWarpLine(int frame_count)
{
    while (leftLine.degree - rightLine.degree>3.14159265)
        rightLine.degree = rightLine.degree + 3.14159265;

    while (rightLine.degree - leftLine.degree>3.14159265)
        leftLine.degree = leftLine.degree + 3.14159265;

    for (int i = 0; i<frame_count; i++)
    {
        double ratio = (double)(i + 1) / (frame_count + 1);
        Line curLine;

        curLine.M.x = (1 - ratio)*leftLine.M.x + ratio*rightLine.M.x;
        curLine.M.y = (1 - ratio)*leftLine.M.y + ratio*rightLine.M.y;
        curLine.len = (1 - ratio)*leftLine.len + ratio*rightLine.len;
        curLine.degree = (1 - ratio)*leftLine.degree + ratio*rightLine.degree;

        curLine.MLDtoPQ();
        warpLine.push_back(curLine);
    }
    return;
}

Image::Image(int index, string leftImageName, string rightImageName)
{
    frame_index = index;

    left_image = imread(leftImageName);
    right_image = imread(rightImageName);

    Size ImageSize = Size(left_image.cols, left_image.rows);
    new_image.create(ImageSize, CV_8UC3);
}

Vec3b Image::bilinear(Mat image, double X, double Y)
{
    int width = image.cols;
    int height = image.rows;

    int x_floor = (int)X;
    int y_floor = (int)Y;
    int x_ceil = x_floor + 1;
    int y_ceil = y_floor + 1;
    double a = X - x_floor;
    double b = Y - y_floor;
    if (x_ceil >= width - 1)
        x_ceil = width - 1;
    if (y_ceil >= height - 1)
        y_ceil = height - 1;
    Vec3b output_scalar;
    Vec3b leftdown = image.at<Vec3b>(y_floor, x_floor);
    Vec3b lefttop = image.at<Vec3b>(y_ceil, x_floor);
    Vec3b rightdown = image.at<Vec3b>(y_floor, x_ceil);
    Vec3b righttop = image.at<Vec3b>(y_ceil, x_ceil);

    for (int i = 0; i < 3; i++)
    {
        output_scalar.val[i] = (1 - a)*(1 - b)*leftdown.val[i] + a*(1 - b)*rightdown.val[i] + a*b*righttop.val[i] + (1 - a)*b*lefttop.val[i];
    }
    return output_scalar;
}

void Image::Warp(int frame_count, string new_image_name, vector<LinePair> pairs)
{
    double ratio = (double)(frame_index + 1) / (frame_count + 1);

    Mat ori_leftImage, ori_rightImage;
    ori_leftImage = left_image;
    ori_rightImage = right_image;

    int width = new_image.cols;
    int height = new_image.rows;


    for (int x = 0; x < width; x++)
    {
        for (int y = 0; y < height; y++)
        {
            Point2f dst_point;
            dst_point.x = x;
            dst_point.y = y;
            double leftXSum_x = 0.0;
            double leftXSum_y = 0.0;
            double leftWeightSum = 0.0;
            double rightXSum_x = 0.0;
            double rightXSum_y = 0.0;
            double rightWeightSum = 0.0;
            for (int i = 0; i < pairs.size(); i++){
                Line src_line = pairs[i].leftLine;
                Line dst_line = pairs[i].warpLine[frame_index];

                double new_u = dst_line.Getu(dst_point);
                double new_v = dst_line.Getv(dst_point);

                Point2f src_point = src_line.Get_Point(new_u, new_v);
                double src_weight = dst_line.Get_Weight(dst_point);
                leftXSum_x = leftXSum_x + (double)src_point.x * src_weight;
                leftXSum_y = leftXSum_y + (double)src_point.y * src_weight;
                leftWeightSum = leftWeightSum + src_weight;

                src_line = pairs[i].rightLine;

                new_u = dst_line.Getu(dst_point);
                new_v = dst_line.Getv(dst_point);

                src_point = src_line.Get_Point(new_u, new_v);
                src_weight = dst_line.Get_Weight(dst_point);
                rightXSum_x = rightXSum_x + (double)src_point.x * src_weight;
                rightXSum_y = rightXSum_y + (double)src_point.y * src_weight;
                rightWeightSum = rightWeightSum + src_weight;
            }

            double left_src_x = leftXSum_x / leftWeightSum;
            double left_src_y = leftXSum_y / leftWeightSum;
            double right_src_x = rightXSum_x / rightWeightSum;
            double right_src_y = rightXSum_y / rightWeightSum;

            if (left_src_x<0)
                left_src_x = 0;
            if (left_src_y<0)
                left_src_y = 0;
            if (left_src_x >= width)
                left_src_x = width - 1;
            if (left_src_y >= height)
                left_src_y = height - 1;
            if (right_src_x<0)
                right_src_x = 0;
            if (right_src_y<0)
                right_src_y = 0;
            if (right_src_x >= width)
                right_src_x = width - 1;
            if (right_src_y >= height)
                right_src_y = height - 1;


            Vec3b left_scalar = bilinear(ori_leftImage, left_src_x, left_src_y);
            Vec3b right_scalar = bilinear(ori_rightImage, right_src_x, right_src_y);
            Vec3b new_scalar;
            new_scalar.val[0] = (1 - ratio)*left_scalar.val[0] + ratio*right_scalar.val[0];
            new_scalar.val[1] = (1 - ratio)*left_scalar.val[1] + ratio*right_scalar.val[1];
            new_scalar.val[2] = (1 - ratio)*left_scalar.val[2] + ratio*right_scalar.val[2];
            new_image.at<Vec3b>(y, x) = new_scalar;
        }

    }
    char win_name[16];
    char img_name[50];
    sprintf(img_name, "%s_%d.jpg", new_image_name.c_str(), frame_index);

    imshow(img_name, new_image);
    imwrite(img_name,new_image);
    return;
}

void Morpher::runWarp()
{
    for (int i = 0; i<frame_count; i++)
    {
        Image curImage = Image(i, first_image_name, second_image_name);
        printf("warping %d...\n", i);
        curImage.Warp(frame_count,new_image_name, pairs);
    }
}



void Morpher::show_pairs()
{
    int len = pairs.size();
    printf("pairs size=%d\n", len);
    for (int i = 0; i<len; i++)
    {
        printf("leftLine:");
        pairs[i].leftLine.show();
        printf("rightLine:");
        pairs[i].rightLine.show();
        printf("\n");
    }
}

void Morpher::on_mousel(int event, int x, int y, int flag, void* param)
{
    Morpher* pm = (Morpher*)param;
    int& counter=pm->counter;
    LinePair& curLinePair = pm->curLinePair;
    Mat& leftImage = pm->leftImage;
    Mat& leftImageTmp = pm->leftImageTmp;
    Scalar& color = pm->color;
    int& thickness = pm->thickness;
    int& shift = pm->shift;

    if (counter % 2 == 0 && pm->counter > 0)
    {
        curLinePair.warpLine.clear();
        if (event == CV_EVENT_LBUTTONDOWN || event == CV_EVENT_RBUTTONDOWN){
            printf("Left image( %d, %d) ", x, y);
            printf("The Event is : %d ", event);
            printf("The flags is : %d ", flag);
            printf("The param is : %d\n", param);
            curLinePair.leftLine.P.x = x;
            curLinePair.leftLine.P.y = y;
            cout << "P:" << curLinePair.leftLine.P.x << '\t' << curLinePair.leftLine.P.y << endl;
        }
        if (event == CV_EVENT_LBUTTONUP || event == CV_EVENT_RBUTTONUP){
            printf("Left image( %d, %d) ", x, y);
            printf("The Event is : %d ", event);
            printf("The flags is : %d ", flag);
            printf("The param is : %d\n", param);
            curLinePair.leftLine.Q.x = x;
            curLinePair.leftLine.Q.y = y;
            curLinePair.leftLine.PQtoMLD();
            cout <<"P:"<< curLinePair.leftLine.P.x <<'\t'<< curLinePair.leftLine.P.y << endl;
            cout << "Q:" << curLinePair.leftLine.Q.x << '\t' << curLinePair.leftLine.Q.y << endl;
            line(leftImage, curLinePair.leftLine.P, curLinePair.leftLine.Q, color, thickness, CV_AA, shift);
            leftImageTmp = leftImage.clone();
            counter--;
        }
        if (flag == CV_EVENT_FLAG_LBUTTON || flag == CV_EVENT_FLAG_RBUTTON){
            curLinePair.leftLine.Q.x = x;
            curLinePair.leftLine.Q.y = y;
            leftImage.release();
            leftImage = leftImageTmp.clone();
            line(leftImage, curLinePair.leftLine.P, curLinePair.leftLine.Q, color, thickness, CV_AA, shift);
            imshow("left", leftImage);
        }
    }
    else
    {
        //cout << "you have selected the wrong image" << endl;
    }
}

void Morpher::on_mouser(int event, int x, int y, int flag, void* param)
{
    Morpher* pm = (Morpher*)param;
    int& counter = pm->counter;
    LinePair& curLinePair = pm->curLinePair;
    Mat& rightImage = pm->rightImage;
    Mat& rightImageTmp = pm->rightImageTmp;
    int& frame_count = pm->frame_count;
    vector<LinePair>& pairs = pm->pairs;
    Scalar& color = pm->color;
    int& thickness = pm->thickness;
    int& shift = pm->shift;

    if (counter % 2 == 1 && counter > 0)
    {
        if (event == CV_EVENT_LBUTTONDOWN || event == CV_EVENT_RBUTTONDOWN){
            printf("right image( %d, %d) ", x, y);
            printf("The Event is : %d ", event);
            printf("The flags is : %d ", flag);
            printf("The param is : %d\n", param);
            curLinePair.rightLine.P.x = x;
            curLinePair.rightLine.P.y = y;
        }
        if (event == CV_EVENT_LBUTTONUP || event == CV_EVENT_RBUTTONUP){
            printf("right image( %d, %d) ", x, y);
            printf("The Event is : %d ", event);
            printf("The flags is : %d ", flag);
            printf("The param is : %d\n", param);
            curLinePair.rightLine.Q.x = x;
            curLinePair.rightLine.Q.y = y;
            curLinePair.rightLine.PQtoMLD();
            line(rightImage, curLinePair.rightLine.P, curLinePair.rightLine.Q, color, thickness, CV_AA, shift);
            rightImageTmp = rightImage.clone();
            counter--;
            curLinePair.genWarpLine(frame_count);
            pairs.push_back(curLinePair);

            printf("\n");
            pm->show_pairs();

            counter = 0;
        }
        if (flag == CV_EVENT_FLAG_LBUTTON || flag == CV_EVENT_FLAG_RBUTTON){
            curLinePair.rightLine.Q.x = x;
            curLinePair.rightLine.Q.y = y;
            rightImage.release();
            rightImage = rightImageTmp.clone();
            line(rightImage, curLinePair.rightLine.P, curLinePair.rightLine.Q, color, thickness, CV_AA, shift);
            imshow("right", rightImage);
        }
    }
    else
    {
        //cout << "you have selected the wrong image" << endl;
    }
}

void Morpher::main()
{
    first_image_name = "test_img/1.jpg";
    second_image_name = "test_img/2.jpg";
    new_image_name = "morph";

    //设置动画的过渡帧数，比如1为50%，3为25%，50%，75%
    frame_count = 3;

    leftImage = imread(first_image_name);
    rightImage = imread(second_image_name);

    leftImageTmp = leftImage.clone();
    rightImageTmp = rightImage.clone();

    namedWindow("left", 1);
    moveWindow("left", 10, 10);
    namedWindow("right", 1);
    moveWindow("right", 300, 10);

    setMouseCallback("left", on_mousel, this);
    setMouseCallback("right", on_mouser, this);

    imshow("left", leftImage);
    imshow("right", rightImage);

    while (true)
    {
        key = waitKey(0);
        if (key == 'c')
            counter =counter + 2;
        else if (key == 'w')
            runWarp();
        else if (key == 'q')
            break;
    }

    imwrite("left_marked.jpg",leftImage);
    imwrite("right_marked.jpg", rightImage);

    return;
}

运行方法及效果

在Morpher类成员函数main()的实现里，指定两幅输入图像的路径字符串。指定输出图像的名称字符串。指定变形过渡的帧数。这里设为3。

    first_image_name = "test_img/1.jpg";
    second_image_name = "test_img/2.jpg";
    new_image_name = "morph";

    //设置动画的过渡帧数，比如1为50%，3为25%，50%，75%
    frame_count = 3;

按下“C”键交互式的在两幅图像上画出对应特征线。每选取一对，按一次“C”键。

按下“W”键，开始warping…

0%:

25%:

50%:

75%:

100%:

其它：
